New Electro-Thermal Battery Pack Model of an Electric Vehicle

Since the evolution of the electric and hybrid vehicle, the analysis of batteries’ characteristics
and influence on driving range has become essential. This fact advocates the necessity of accurate
simulation modeling for batteries. Different models for the Li-ion battery cell are reviewed in this
paper and a group of the highly dynamic models is selected for comparison. A new open circuit
voltage (OCV) model is proposed. The new model can simulate the OCV curves of lithium iron
magnesium phosphate (LiFeMgPO$_{4}$) battery type at different temperatures. It also considers both
... mehr
charging and discharging cases. The most remarkable features from different models, in addition
to the proposed OCV model, are integrated in a single hybrid electrical model. A lumped thermal
model is implemented to simulate the temperature development in the battery cell. The synthesized
electro-thermal battery cell model is extended to model a battery pack of an actual electric vehicle.
Experimental tests on the battery, as well as drive tests on the vehicle are performed. The proposed
model demonstrates a higher modeling accuracy, for the battery pack voltage, than the constituent
models under extreme maneuver drive tests.

Since the evolution of the electric and hybrid vehicle, the analysis of batteries’ characteristics and influence on driving range has become essential. This fact advocates the necessity of accurate simulation modeling for batteries. Different models for the Li-ion battery cell are reviewed in this paper and a group of the highly dynamic models is selected for comparison. A new open circuit voltage (OCV) model is proposed. The new model can simulate the OCV curves of lithium iron magnesium phosphate (LiFeMgPO4) battery type at different temperatures. It also considers both charging and discharging cases. ... mehrThe most remarkable features from different models, in addition to the proposed OCV model, are integrated in a single hybrid electrical model. A lumped thermal model is implemented to simulate the temperature development in the battery cell. The synthesized electro-thermal battery cell model is extended to model a battery pack of an actual electric vehicle. Experimental tests on the battery, as well as drive tests on the vehicle are performed. The proposed model demonstrates a higher modeling accuracy, for the battery pack voltage, than the constituent models under extreme maneuver drive tests.
