Sodiophilic Current Collectors Based on MOF‐Derived Nanocomposites for Anode‐Less Na‐Metal Batteries

Li, Huihua 1; Zhang, Huang 1; Wu, Fanglin 1; Zarrabeitia, Maider ORCID iD icon 1; Geiger, Dorin; Kaiser, Ute; Varzi, Alberto ORCID iD icon 1; Passerini, Stefano 1
1 Helmholtz-Institut Ulm (HIU), Karlsruher Institut für Technologie (KIT)

Abstract:

“Anode-less” sodium metal batteries (SMBs) with high energy may become the next-generation batteries due to the abundant resources. However, their cycling performance is still insufficient for practical uses. Herein, a metal organic frameworks (MOF)-derived copper-carbon (Cu@C) composite is developed as a sodiophilic layer to improve the Coulombic efficiency (CE) and cycle life. The Cu particles can provide abundant nucleation sites to spatially guide Na deposition and the carbon framework offer void volume to avoid volume changes during the plating/stripping process. As a result, Cu@C-coated copper and aluminum foils (denoted as Cu-Cu@C and Al-Cu@C foil) can be used as efficient current collectors for sodium plating/stripping, achieving, nearly 1600 and 240 h operation upon cycling at 0.5 mA cm$^{-2}$ and 1 mA h cm$^{-2}$, respectively. In situ dilatometry measurements demonstrate that Cu@C promotes the formation of dense Na deposits, thereby inhibiting side reactions, dendrite growth, and accumulation of dead Na. Such current collectors are employed in Na metal cells using carbon-coated Na$_{3}$V$_{2}$(PO$_{4}$)$_{3}$ (NVP/C) and copper selenides (Cu$_{2-x}$Se@C) cathodes, achieving outstanding rate capability and improved cycling performance. ... mehr


Verlagsausgabe §
DOI: 10.5445/IR/1000151492
Veröffentlicht am 24.10.2022
Originalveröffentlichung
DOI: 10.1002/aenm.202202293
Scopus
Zitationen: 49
Web of Science
Zitationen: 43
Dimensions
Zitationen: 49
Cover der Publikation
Zugehörige Institution(en) am KIT Helmholtz-Institut Ulm (HIU)
Publikationstyp Zeitschriftenaufsatz
Publikationsjahr 2022
Sprache Englisch
Identifikator ISSN: 1614-6832, 1614-6840
KITopen-ID: 1000151492
HGF-Programm 38.02.01 (POF IV, LK 01) Fundamentals and Materials
Erschienen in Advanced Energy Materials
Verlag Wiley-VCH Verlag
Band 12
Heft 43
Seiten Art.-Nr.: 2202293
Vorab online veröffentlicht am 20.09.2022
Nachgewiesen in Dimensions
Web of Science
Scopus
Globale Ziele für nachhaltige Entwicklung Ziel 7 – Bezahlbare und saubere Energie
