380 kV Superconducting Fault Current Limiter Feasibility Study
Noe, Mathias
1; Humpert, Chistof; De Sousa, Wescley
1; Fink, Stefan
1; Herzog, Friedhelm; Huwer, Stefan; Nießen, Marvin; Pfaller, Sebastian; Pöhler, Stephan; Rodler, Tobias; Schmid, André; Arndt, Tabea
1
1 Institut für Technische Physik (ITEP), Karlsruher Institut für Technologie (KIT)
1; Humpert, Chistof; De Sousa, Wescley
1; Fink, Stefan
1; Herzog, Friedhelm; Huwer, Stefan; Nießen, Marvin; Pfaller, Sebastian; Pöhler, Stephan; Rodler, Tobias; Schmid, André; Arndt, Tabea
11 Institut für Technische Physik (ITEP), Karlsruher Institut für Technologie (KIT)
Abstract:
In this study the technical and economic feasibility of a 380 kV, 5 kA resistive type superconducting fault current limiter was investigated. Conceptual designs were developed with superconducting tapes cooled by liquid nitrogen and arranged in bifilar coils. A cryostat was designed using FEM simulations taking into account the non-linear voltage distribution. For the complete system including current limiting reactors and cooling system, the investment and operation costs were calculated.
| Zugehörige Institution(en) am KIT | Institut für Technische Physik (ITEP) |
| Publikationstyp | Forschungsbericht/Preprint |
| Publikationsjahr | 2023 |
| Sprache | Englisch |
| Identifikator | ISBN: 978-3-7315-1313-1 ISSN: 1869-1765 KITopen-ID: 1000161057 |
| HGF-Programm | 38.05.03 (POF IV, LK 01) High Temperature Superconductivity |
| Verlag | KIT Scientific Publishing |
| Umfang | XIX, 131 S. |
| Serie | Karlsruher Schriftenreihe zur Supraleitung / Hrsg. Prof. Dr.-Ing. M. Noe, Prof. Dr. rer. nat. M. Siegel ; 37 |
| Schlagwörter | Supraleiter, supraleitender Strombegrenzer, Hochspannung, bifilare Spule, wirtschaftliche Machbarkeit, superconductor, superconducting fault current limiter, high voltage, bifilar coil, economic feasibility |
