3D anisotropic Finite-Difference modelling on the standard staggered grid

Mai, Daniel 1; Ritter, Joachim 1
1 Geophysikalisches Institut (GPI), Karlsruher Institut für Technologie (KIT)

Abstract:

3D anisotropic modelling is becoming more important to resolve more complex structures.
Therefore, I implemented a new algorithms into an already existing program to be able to
simulate anisotropy. This implementation models with finite differences on the standard stag-
gered grid. For complex anisotropic structures a wavefield interpolation is necessary. I have
implemented to interpolation options and compared them. There are the common sinc-function
interpolation and the FD-consistent interpolation which was not used in this context, yet.
I look at the stability of the algorithm and compare different modelling methods. Most results
are as expected and indicate the algorithm works. The FD-consistent interpolation seems to
be a lot more consistent than the sinc-function interpolation and it requires a lower spatial FD
order to do so.

Zugehörige Institution(en) am KIT Geophysikalisches Institut (GPI)
Publikationstyp Hochschulschrift
Publikationsdatum 06.09.2024
Sprache Englisch
Identifikator KITopen-ID: 1000180727
Verlag Karlsruher Institut für Technologie (KIT)
Art der Arbeit Abschlussarbeit - Master
Schlagwörter seismic anisotropy, Finite Difference seismic modeling
Referent/Betreuer Bohlen, Thomas

Volltext §
DOI: 10.5445/IR/1000180727
Veröffentlicht am 02.04.2025
