Helically corrugated waveguide with dielectric lined drift section for a 263 GHz gyro-TWT
Vöhringer, Max 1; Marek, Alexander
1; Illy, Stefan 1; Thumm, Manfred 1; Feuerstein, Lukas
1; Wu, Chuanren
1; Jelonnek, John 1
1 Institut für Hochleistungsimpuls- und Mikrowellentechnik (IHM), Karlsruher Institut für Technologie (KIT)
1; Illy, Stefan 1; Thumm, Manfred 1; Feuerstein, Lukas
1; Wu, Chuanren
1; Jelonnek, John 11 Institut für Hochleistungsimpuls- und Mikrowellentechnik (IHM), Karlsruher Institut für Technologie (KIT)
Abstract (englisch):
Gyro-TWTs with helically corrugated interaction region (HCIR) have shown to be effective for broadband and high-power amplification of signals up to the W-band. In this
publication, versions for 263 GHz (G-band) are proposed, which are able to generate above 1 kW of output power with a gain of 30 dB and 50 dB respectively. To avoid self-oscillations, a dielectric lined drift section is introduced and its effect on the interaction investigated. Furthermore, the effect of a non-ideal electron beam on the amplifier gain is examined. It is found that it has a great influence on the bandwidth; its influence on the maximum gain, however, is limited.
publication, versions for 263 GHz (G-band) are proposed, which are able to generate above 1 kW of output power with a gain of 30 dB and 50 dB respectively. To avoid self-oscillations, a dielectric lined drift section is introduced and its effect on the interaction investigated. Furthermore, the effect of a non-ideal electron beam on the amplifier gain is examined. It is found that it has a great influence on the bandwidth; its influence on the maximum gain, however, is limited.
| Zugehörige Institution(en) am KIT | Institut für Hochleistungsimpuls- und Mikrowellentechnik (IHM) |
| Publikationstyp | Proceedingsbeitrag |
| Publikationsdatum | 17.03.2025 |
| Sprache | Englisch |
| Identifikator | ISBN: 978-3-9820397-4-9 ISSN: 2167-8022 KITopen-ID: 1000182036 |
| HGF-Programm | 31.13.02 (POF IV, LK 01) Plasma Heating & Current Drive Systems |
| Erschienen in | 2025 16th German Microwave Conference (GeMiC), Dresden, 17th-19th March 2025 |
| Veranstaltung | 16th German Microwave Conference (GeMiC 2025), Dresden, Deutschland, 17.03.2025 – 19.03.2025 |
| Verlag | Institute of Electrical and Electronics Engineers (IEEE) |
| Seiten | 211–214 |
| Projektinformation | SFB 1527; HyPERiON, 454252029 (DFG, DFG KOORD, SFB 1527_1) |
| Schlagwörter | gyrotron traveling wave amplifier, broadband, amplification, helically corrugated waveguide |
