The Future Circular Collider (FCC) project and its cryogenic challenges

Tavian, Laurent


Following the update of the European strategy in particle physics, CERN has undertaken an international study of possible future circular colliders beyond the LHC. The study considers several options for very high-energy hadron-hadron, electron-positron and hadron-electron colliders. From the cryogenics point of view, the most challenging option is the hadron-hadron collider (FCC-hh). The FCC-hh cryogenic system will have to produce up to 120 kW at 1.8 K for the superconducting magnet cooling, 6 MW between 40 and 60 K for the beam-screen and thermal-shield cooling as well as 850 g/s between 40 and 290 K for the HTS current-lead cooling. The corresponding total entropic load represents about 1 MW equivalent at 4.5 K and this cryogenic system will be by far the largest ever designed. In addition, the total mass to be cooled down is about 250’000 t and an innovative cool-down process must be proposed. This talk will present the proposed cryogenic layout and architecture, the cooling principles of the main components, the corresponding cooling schemes, as well as the cryogenic plant arrangement and proposed process cycles with emphasis to the main cryogenic challenges.

Volltext §
DOI: 10.5445/IR/1000074518
Cover der Publikation
Zugehörige Institution(en) am KIT Institut für Technische Physik (ITEP)
Publikationstyp Vortrag
Publikationsjahr 2017
Sprache Englisch
Identifikator urn:nbn:de:swb:90-745180
KITopen-ID: 1000074518
HGF-Programm 37.06.02 (POF III, LK 01) New Power Network Technology
Veranstaltung European Cryogenic Days (ECD) 2017, Karlsruhe, Germany, 13th - 15th September 2017
Bemerkung zur Veröffentlichung Author affiliation: European Organization for Nuclear Research (CERN), Switzerland
