Cascaded H-Bridge based Parallel Hybrid Converter – A new Voltage Source for Power-Hardware-in-the-Loop Emulation Systems
Stefanski, Lukas
1; Schwendemann, Rüdiger 1; Bernet, Daniel 1; Widenmeyer, Martin 1; Liske, Andreas 1; Hiller, Marc 1
1 Elektrotechnisches Institut (ETI), Karlsruher Institut für Technologie (KIT)
1; Schwendemann, Rüdiger 1; Bernet, Daniel 1; Widenmeyer, Martin 1; Liske, Andreas 1; Hiller, Marc 11 Elektrotechnisches Institut (ETI), Karlsruher Institut für Technologie (KIT)
Abstract:
This paper presents a new 50 kVA Parallel Hybrid Converter (PHC) for Power-Hardware-in-the-Loop (PHIL) emulation systems. The converter combines the high output voltage quality of a low power 17-level Cascaded H-Bridge (CHB) converter in star configuration with the high efficiency and high power density of a 2-level converter. The requirements a converter topology must fulfill in order to be used for PHIL emulation systems are derived and it is shown, that the PHC topology characteristics ideally meet these requirements.
| Zugehörige Institution(en) am KIT | Elektrotechnisches Institut (ETI) |
| Publikationstyp | Proceedingsbeitrag |
| Publikationsdatum | 09.11.2020 |
| Sprache | Englisch |
| Identifikator | ISBN: 978-1-7281-7161-6 KITopen-ID: 1000127109 |
| HGF-Programm | 37.06.01 (POF III, LK 01) Networks and Storage Integration |
| Erschienen in | 2020 IEEE 21st Workshop on Control and Modeling for Power Electronics (COMPEL), Aalborg, Denmark, Denmark, 9-12 Nov. 2020 |
| Veranstaltung | 21st Workshop on Control and Modeling for Power Electronics (COMPEL 2020), Aalborg, Dänemark, 09.11.2020 – 12.11.2020 |
| Verlag | Institute of Electrical and Electronics Engineers (IEEE) |
| Seiten | Art.Nr. 9265820 |
| Schlagwörter | Parallel Hybrid Converter (PHC), energy and balancing control, predictive current control, Power-Hardware-in-the-Loop, Cascaded H-Bridge Converter (CHB), Modular Multilevel Converter (MMC) |
